Product Details:
Place of Origin: CHINA
Brand Name: MEILI
Certification: CE ISO9001
Payment & Shipping Terms:
Minimum Order Quantity: 1pcs
Price: Negotiable
Packaging Details: Iron Pallet
Delivery Time: In 60days
Payment Terms: T/T, L/C, D/A, D/P
Supply Ability: 80 Sets per Month

10ton Electric Servo Press 750mm 11KW CNC Automotive Industry

Description
Product Name: 10ton Electric Servo Press For Sale Usage: Assembly Press
After Warranty Service: 250mm Voltage: 750mm
System: Servo Cnc Or Not: CNC
Material: Steel Material Warranty: 2 Years
High Light:

10ton Electric Servo Press

,

Electric Servo Press 11KW

,

servo press machine CNC

10ton Electric Servo Press 750mm 11KW CNC Automotive Industry

10ton Electric servo press for sale


Major features:

1). Energy saving and emission reduction: Hydraulic and electronic control adopt intelligent servo-saving system, saving 50-70%



2). Safety & Precision: Each machine is equipped with an infrared safety grating, which effectively protects the safety of the operator. The servo intelligent patented control system ensures that the machine’s repeat position accuracy is up to ± 0.03mm and the pressure precision is ± 1 bar.



3). Low failure rate: Servo intelligent patent control system, do not useless work, the oil temperature is not easy to increase, and there is no negative pressure in the oil system, a greater reduction of failure, prolong the service life of hydraulic components, electrical appliances with automatic fault alarm function and one-button reset function.





Description Unit 0.5T 1T 2T 3T 4T 5T 8T 10T 20T
Nominal Force T 0.5T 1T 2T 3T 4T 5T 8T 10T 20T
Table size L-R mm 300 300 400 400 400 500 500 500 600
F-B mm 250 250 320 320 320 440 440 440 500
Max daylight mm 300 300 300 350 400 450 500 500 500
Stroke of slider mm 120 120 150 200 250 250 300 350 350
Down speed mm/s 0-80
Working speed mm/s 0-15
Return speed mm/s 0-80
Throat Depth mm 120 120 160 160 180 250 250 250 280
Operation Height mm 750 750 750 750 750 750 750 750 750
Powder of motor KW 1 2 2 3 4 5 7.8 11 20
