Product Details:
Place of Origin: CHINA
Brand Name: MEILI
Certification: CE ISO9001
Payment & Shipping Terms:
Minimum Order Quantity: 1pcs
Price: Negotiable
Packaging Details: Iron Pallet
Delivery Time: In 60days
Payment Terms: T/T, L/C, D/A, D/P
Supply Ability: 80 Sets per Month

1.5KW Bench Hydraulic Press 1T Bench Shop Press 1KN C Type Hydraulic Table Press

Description
Product Name: Cheap Bench Hydraulic Presses Factory In China Force: 1T
Operation Height: 200mm Down Speed Of Slider: 60mm/s
Type: C Frame Return Speed Of Slider: 80mm/s
Keywords: Bench Hydraulic Presses Powder Of Motor: 1.5KW
High Light:

1.5KW bench hydraulic press

,

bench hydraulic press 1T

,

C Type Hydraulic Table Press

Cheap Bench Hydraulic Presses Factory in China



Features:

1. The steel body is entirely welded with steel plates, and treated to relive stress by tempering

2. Cartridge valve integral unit equipment for hydraulic control system, reliable, durable and less hydraulic shock, with shorter connection pipeline and fewer releases points.

3. Independent electrical control, reliable, audio-visual and convenient for maintenance.

4. Centralized button control system, with adjustment, hand and semi-auto operation modes.

5. Fixed stroke forming process of fixed pressure forming process selected through control panel, with pressure hold and time delay functions.

6. The operating force, no-load traveling and, low-speed movement and travel range can be adjusted subject to technological requirements.



Description Unit 1T 1.6T 2.5T 4T 5T
Nominal Force KN 1 1.6 2.5 4 5
Table size L-R mm 300 300 350 350 350
F-B mm 250 250 300 300 350
Max opening height mm 300 300 350 350 350
Max stroke of slider mm 120 120 160 160 200
Throat Depth mm 120 120 160 160 180
Down speed of slider mm/s 60 50 42 42 42
Return speed of slider mm/s 80 80 80 80 80
Operation Height mm 200 200 200 200 200
Powder of motor KW 1.5 1.5 2.2 2.2 3


1.5KW Bench Hydraulic Press 1T Bench Shop Press 1KN C Type Hydraulic Table Press 0

1.5KW Bench Hydraulic Press 1T Bench Shop Press 1KN C Type Hydraulic Table Press 1



1.5KW Bench Hydraulic Press 1T Bench Shop Press 1KN C Type Hydraulic Table Press 2
