4 Post High Speed Hydraulic Press Machine with TPC PLC Moto Pump

4 Post High Speed Hydraulic Press Machine with TPC PLC Moto Pump
4 Post High Speed Hydraulic Press Machine with TPC PLC Moto Pump

Large Image :  4 Post High Speed Hydraulic Press Machine with TPC PLC Moto Pump

Product Details:
Place of Origin: CHINA
Brand Name: MEILI
Certification: CE ISO9001
Payment & Shipping Terms:
Minimum Order Quantity: 1pcs
Price: Negotiable
Packaging Details: Iron Pallet
Delivery Time: In 60days
Payment Terms: T/T, L/C, D/A, D/P
Supply Ability: 80 Sets per Month

4 Post High Speed Hydraulic Press Machine with TPC PLC Moto Pump

Description
Product Name: 10 Ton High Speed Hydraulic Presses Manufacturer In China Force: 10T
Down Speed Of Slider: 150mm/s Return Speed Of Slider: 120mm/s
Operation Height: 710mm Powder Of Motor: 2.2KW
High Light:

4 Post high speed press machine

,

high speed press machine TPC

,

High Speed Hydraulic Press TPC PLC

10 ton High Speed Hydraulic presses manufacturer in China.



MEILI C-type Hydraulic Press is a kind of multifunctional machine which has strong generality. It is suitable for the press fitting of shaft components and axle sleeve parts as well as the movements of coining and overprinting. It can also be used to press powder and plastic products which the requirements are not strict. At the same time, it mainly applies to the fields of machine tool, engineering machinery, electrical components, bearings, washing machine, automobile parts and motor components. It can even be used as assembly line. The pressure, stroke, and time of pressure maintaining can be regulated.





Our product offerings include:
Multi-action Presses
C-Frame Presses (1-300 tons)
4-Post Presses (up to 1,200 tons)
H-Frame Presses(up to 1,200 tons)
Service
Maintenance
Spare Parts





Features:

• This structure of this C Frame press looks like letter "C" and all parts and installed in the machine body which facilitate easy and safe operation.

• C Frame high strength structure design with three sides open for easy material loading and product unloading as well as easy connecting with other corollary equipment.

• This C Frame hydraulic punching press can be tailor made to meet different application requirements.









Description Unit 10T 16T 25T 40T 63T 100T 200T 250T 315T 400T
Nominal Force KN 10 16 25 40 63 100 200 250 315 400
Table size L-R mm 500 600 600 600 700 800 900 900 900 900
F-B mm 440 500 600 550 600 600 650 650 700 700
Slider L-R mm 400 400 450 500 500 500 700 800 800 800
F-B mm 300 350 350 400 450 450 550 650 700 700
Hydraulic cushion Force T   500 600 700 700 700 700
Stroke mm 400 400 450 450 500 500
Max opening height mm 500 550 600 700 800 800 800 800 900 900
Stroke of slider mm 300 350 350 400 500 500 500 500 500 500
Throat Depth mm 250 280 280 300 300 325 325 400 400 400
Down speed of slider mm/s 150 150 150 150 150 150 150 150 120 120
Working speed of slider mm/s 10-15adjustable
Return speed of slider mm/s 120 120 120 120 120 120 110 110 87 85
Operation Height mm 710
Powder of motor KW 2.2 2.2 2.2 4 5.5 5.5 7.5 11 18.5 22
Total weight T 1 1.5 2 2.5 3.5 4.5 7.5 9.6 15 20

4 Post High Speed Hydraulic Press Machine with TPC PLC Moto Pump 0



4 Post High Speed Hydraulic Press Machine with TPC PLC Moto Pump 1



4 Post High Speed Hydraulic Press Machine with TPC PLC Moto Pump 2



Contact MEILIPRESS if your business:
Struggles with accuracy, quality or repeatability with your current machines.And want a new one.
