Electric Hydraulic Assembly Press PLC 0.01mm Accuracy Motor Industry

Electric Hydraulic Assembly Press PLC 0.01mm Accuracy Motor Industry
Electric Hydraulic Assembly Press PLC 0.01mm Accuracy Motor Industry Electric Hydraulic Assembly Press PLC 0.01mm Accuracy Motor Industry

Large Image :  Electric Hydraulic Assembly Press PLC 0.01mm Accuracy Motor Industry

Product Details:
Place of Origin: CHINA
Brand Name: MEILI
Certification: CE ISO9001
Payment & Shipping Terms:
Minimum Order Quantity: 1pcs
Price: Negotiable
Packaging Details: Iron Pallet
Delivery Time: In 60days
Payment Terms: T/T, L/C, D/A, D/P
Supply Ability: 80 Sets per Month

Electric Hydraulic Assembly Press PLC 0.01mm Accuracy Motor Industry

Description
Product Name: Electric Hydraulic Press For Assembly Unit: 5T
Max Daylight: 450mm Stroke Of Slider: 250mm
System: Servo Cnc Or Not: CNC
Voltage: 220V/380V(According To Requirement) Warranty: 2 Years
High Light:

hydraulic assembly press 0.01mm

,

hydraulic assembly press PLC

,

electric hydraulic press Motor Industry

Electric hydraulic press for assembly




Features:

1. High efficiency, multiple protections inside, and extremely low failure rate.

2.12 hours of continuous work without cooling oil temperature.

3. Pipes and joints adopt SEA international standards to prevent pipeline oil leakage.

4. Adopt button centralized control, (fixed distance / constant pressure) two control methods, (adjustment / automatic) two operation methods

5. standard hydraulic system and electrical appliance safety IP54 level.





Description Unit 0.5T 1T 2T 3T 4T 5T 8T 10T 20T
Nominal Force T 0.5T 1T 2T 3T 4T 5T 8T 10T 20T
Table size L-R mm 300 300 400 400 400 500 500 500 600
F-B mm 250 250 320 320 320 440 440 440 500
Max daylight mm 300 300 300 350 400 450 500 500 500
Stroke of slider mm 120 120 150 200 250 250 300 350 350
Down speed mm/s 0-80
Working speed mm/s 0-15
Return speed mm/s 0-80
Throat Depth mm 120 120 160 160 180 250 250 250 280
Operation Height mm 750 750 750 750 750 750 750 750 750
Powder of motor KW 1 2 2 3 4 5 7.8 11 20
